Sony Digital Media Receiver with WebLink Cast 178 x 100 x 139mm - XAVAX3200

Contents : 1 x Sony Digital Media Receiver with WebLink Cast

Description

Enjoy smartphone connectivity including screen mirroring with WebLink and hear the rich sound from the powerful 4 x 55 W amplification and EXTRA BASS™ boost. The anti-glare 6.95" (17.6cm) touchscreen wakes up soon after turning on the ignition and gives you intuitive control over your music, phone calls and much more.

Specifications

Size & Weight

DIMENSIONS (W X H X D) : 178x100x139mm
WEIGHT : 1.0kg

General Features

EQUALIZER : 10-band Graphic Equalizer
EXTRA BASS : Yes (Off / 1 / 2)
FIRMWARE UPGRADABILITY : Yes
OUTPUT POWER : 55W x 4
PRE OUT : 3 Pre (Front / Rear / Sub x 1)
REAR VIEW CAMERA IN : Yes
DSO (DYNAMIC STAGE ORGANIZER) : Yes
USB : Yes (Rear x1)

Tuner Features

AUTO MEMORY : BTM
PRESET : FM18 / AM12
RDS / EON : Yes (RDS)

Bluetooth® Profile

A2DP : Yes (1.3)
AVRCP : Yes (1.3)
HFP : Yes (1.6)
PBAP : Yes (1.1)

Bluetooth® Feature

ALPHABETICAL PHONEBOOK SORTING : Yes
BATTERY REMINDER : Yes
CALL VOLUME LEVEL CONTROL : Yes
EXTERNAL MICROPHONE : Supplied
LAST DIALED CALL : Yes (select from the dialed call history)
PHONEBOOK ACCESS VIA PBAP : Yes
RECENT CALLS (# OF) : Yes
RING VOLUME LEVEL CONTROL : Yes
SIGNAL STRENGTH INDICATION : Yes
SPEED DIAL : Yes (6 memories)

Bluetooth® Audio Feature

AUDIO CODEC (BLUETOOTH AUDIO) : SBC / AAC
AUDIO LEVEL ADJUSTMENT : Yes (-6dB to +6dB)
CUE / REV : Yes
GROUP (FOLDER) +/- : Yes
META DATA INDICATION : Yes
PAUSE (BLUETOOTH AUDIO) : Yes
REPEAT CONTROL (AUDIO DEVICE SIDE) : Yes
SHUFFLE CONTROL (AUDIO DEVICE SIDE) : Yes
TRACK +/- : Yes

Panel Design

KEY ILLUMINATION : Yes (White)
PANEL SURFACE FINISH COLOR : Black

Monitor(AVC)

BRIGHTNESS : 500cd / m2
CONTRAST RATIO : 400
DIMMER : Yes
LCD TYPE : TFT Active Matrix
RESOLUTION (DOT) : 800 x 480
SCREEN ASPECT : 0.714583333333333
SCREEN DIAGONAL (INCH / CM) : 6.95 inch

Display Panel

DIMMER ADJUST : Yes
KEY ILLUMINATION INITIAL : Yes (White)

User Interface

ASPECT RATIO SELECT : Yes
GESTURE COMMAND : Yes
PARKING CONTROL : Yes
PARKING LINE ADJUST : Yes
REAR VIEW CAMERA-IN MARKER SETTING : Yes
REMOTE COMMANDER : RM-X170
TOUCH PANEL : Yes / Resistive / AG

USB Mass Storage Device Control Feature

USB DEVICE CONTROL (AUDIO CODEC) : PCM / MP3 / WMA / AAC / FLAC
USB DEVICE CONTROL (AUDIO PLAYABLE FILE EXTENSION) : .wav / .mp3 / .wma / .m4a / .flac
USB DEVICE CONTROL (PAUSE) : Yes
USB DEVICE CONTROL (REPEAT) : TRACK / FOLDER / DRIVE
USB DEVICE CONTROL (RESUME PLAY) : Yes
USB DEVICE CONTROL (SHUFFLE) : OFF / FOLDER / DEVICE
USB DEVICE CONTROL (VIDEO CODEC) : MPEG4-SP / AVC (H.264 Baseline) / WMV / MKV / XviD
USB DEVICE CONTROL (VIDEO PLAYABLE FILE EXTENSION) : .mp4 / .wmv / .mkv

Multi-Language

CAUTION : English / Spanish / French / German / Italian / Russian / Portuguese / Thai / Simplified Chinese / Traditional Chinese / Korean / Arabic / Indonesian
ID3 TAG : English / Spanish / French / German / Italian / Russian / Portuguese / Thai / Simplified Chinese / Traditional Chinese / Korean / Arabic / Indonesian
MENU : English / Spanish / French / German / Italian / Russian / Portuguese / Thai / Simplified Chinese / Traditional Chinese / Korean / Arabic / Indonesian

Connectivity

BLUETOOTH® : Yes

What's In The Box : External Microphone / Remote / Instruction Manual

Features

Siri with Apple CarPlay

Easily access the iPhone features you know and love, just by talking to Siri. Music, maps, phone calls and messages are all under your control.

Voice Control with Android Auto

Use voice commands to dictate messages, take phone calls, or get help from Google Maps. You can even control music playback, just by talking.

WebLink™ Cast compatible

WebLink™ is a lightweight app delivery platform designed especially for in-vehicle use. Using the Android or iOS device connection, it is now possible to mirror your smartphone screen right on the car audio display-for reliable, responsive infotainment anytime on the road.

Anti-glare clear responsive touchscreen

The anti-glare 6.95" (17.6cm) touchscreen gives you intuitive control over music playback, making phone calls and more.

Easy installation with a compact rear chassis

Despite its double-DIN display, the rear chassis is far smaller than conventional double-DIN units. This makes for much easier installation and leaves plenty of room for cabling and other accessories in the space behind the display.

A/V input connectivity

A composite video and stereo audio input terminal enables connection with an external source device.

Build your own sound system

With the three pre-outs you can add components of your choice, like extra amplifiers or subwoofers.

Rear camera ready for easy reversing

If you've got a rear camera installed, you can use it to help you park. Whenever you tap the rear camera icon or put your vehicle in reverse, the video feed instantly comes up on screen. Customisable guidelines help you to back in smoothly and safely.

Bluetooth® wireless technology

Make hands-free calls and stream wireless audio from your smartphone with Bluetooth®.

Powerful, clear amplification

Advanced signal processing from the 4 x 55 W Dynamic Reality Amp 2 removes interference, so music sounds clear and detailed, even when you crank up the volume.

Dynamic Stage Organiser creates virtual speakers on your dashboard

Sound waves are directional, especially in the higher frequencies-so if your speakers are positioned low in your doors, high-frequency sounds are often lost, reducing clarity and instrument separation. Dynamic Stage Organiser uses digital signal processing to lift the sound, improving stereo positioning so music sounds like it's coming from right in front of you.

FLAC compatible

FLAC compatibility lets you play lossless audio files, so you can enjoy every detail of the music.

Quick Wake-up

With the Quick Wake-up feature, you're ready to go, right after turning the ignition.
