Sony Class D Stereo Amplifier Integrated Active Thermal Control - XMGS100

Contents :

1 x Sony Class D Stereo Amplifier

Description

The XM-GS100 amplifier's compact framework and single-sided connections provide multiple mounting options while maximising your audio output. Integrated Active Thermal Control regulates the unit's operating temperature for stable, long-term playback at high volume, while Dynamic Distortion Suppressor enables clear bass reproduction.

Specifications

Size & Weight
DIMENSIONS (W X H X D) : 272 x 51 x 202 mm
WEIGHT : 2.5 kg

Amplifier
CHANNEL CONFIGURATION : Mono
LOW PASS FILTER : 50-300Hz
LOW PASS FILTER SLOPE : 12dB/oct

Rated Output Power, RMS 20 - 20000 Hz
MAX. CHANNEL CONFIGURATION AT 4 OHM (W) / THD (%) : 330W x 1 / 1.0% (20-200Hz)
MAX. CHANNEL CONFIGURATION AT 2 OHM (W) / THD (%) : 600W x 1 / 1.0% (50Hz)

Maximum Output Power (1 kHz)
MAX. CHANNEL POWER CONFIGURATION AT 4 OHM : 600W x 1
MAX. CHANNEL POWER CONFIGURATION AT 2 OHMS : 1100W x 1

General Features
FREQUENCY RESPONSE : 10-300Hz
TOLERANCE : +0.5/-3dB
SIGNAL TO NOISE RATIO : 100dB
TOTAL HARMONIC DISTORTION AT 1 KHZ (%) : 0.1% (50Hz)

Details
CTA POWER OUTPUT : 330W x 1
CTA SN RATIO : 65dBA
LOAD CAPABILITY (OHM) : NO / YES
MOSFET : YES
SUBSONIC HIGH PASS FILTER : YES
BASS BOOST: FREQUENCY (0 - 10 DB) : 40Hz
SPEAKER LEVEL INPUT : YES
LINE IN: INPUT SENSITIVITY : 0.3-6
GOLD PLATED CONNECTORS : YES
CURRENT DRAIN (A) - RATED OUTPUT POWER AT 4 OHMS : 30A
LINE OUT : YES (Through)

What's In The Box
Warranty card / Instruction Manual
