Contents : Knipex Electronics End Cutting Nipper

• Precision pliers for ultra fine cutting work, e. g. in electronics and fine mechanics
• Sturdy, zero backlash box joint
• Low-friction double spring for gentle and even opening
• The polish or mirror polish together with a fine film of oil offer effective rust protection - no circuit faults caused by peeling chrome from plated tools
• Cutters additionally laser hardened, cutter hardness at least 56 HRC
• Oblique End Cutter, short head, with small bevel, ¦Á = 27°
• Ball bearing chrome steel, oil hardened

• Head : mirror polished
• Handles : with multi-component grips
• Weight : 70 g
• Dimensions : 115 x 68 x 17 mm
• Standard : DIN ISO 9654
• REACH compliant : does not contain SVHC
• RoHS compliant : not applicable
• Cutting capacities soft wire (diameter) : Ø 1.5 mm
• Cutting capacities medium hard wire (diameter) : Ø 1.0 mm
• Cutting capacities hard wire (diameter) : Ø 0.5 mm
• Head width (A) : 11 mm
• Jaw length (B) : 10 mm
• Jaw thickness (joint) (D) : 7 mm
• Cutting edge length mm (C) : 12 mm

For cutting fine wire and cable from the front at an angle of 27° to the surface

Cutting at an angle of 27° to the surface and almost flush

In tight spaces, e.g. on printed circuit boards, cutting is often best done from above. Knipex has the electronics end cutting nippers in its range for this purpose. Unlike with diagonal cutters, where the cutting edges are a relatively straight extension of the handle, the cutting edges of the electronics end cutting nippers are at an angle of 27° to the handles. This permits work at an angle to surfaces from which wire, cable or components are protruding. The small bevel means that almost flush cutting is possible using the 64 42 115 electronics end cutting nippers.

Sophisticated design - designed for ergonomics and durability

These Knipex electronics end cutting nippers have a smooth operating box joint with zero backlash. Such joints are characterised by the fact that the inner handle is guided on both sides by two extensive bearing surfaces. This prevents the tilting movements which occur with lap joints, and has a positive effect on the quality of cutting processes and tool life. In addition to oil hardening of the entire pliers, the cutting edges are induction hardened to at least 60 HRC. The low friction double spring is an advantage ergonomically. It produces a gentle, steady opening after cutting.

High Knipex quality standards and safety rust protection

Instead of chrome-plating, this electronics end cutting nippers have a mirror polish and a fine oil film as corrosion protection. With occasional re-oiling of the surface, this rust protection is completely sufficient for workshop operation. As a result, for safety reasons these electronics pliers are also ideal for sensitive electronics environments. There are no pieces of chrome that could peel off and damage circuits. The quality machining of the pliers corresponds to the needs of electronics and micromechanics: high requirements regarding precision, function and reliability.
