Heavy Duty Air Bag Suspension Load Assist Kit for Ford Ranger New Gen 22-On 4WD

Contents:

1 x Heavy Duty Air Bag Suspension Load Assist Kit

Suit:

Ford Ranger New Gen 2022-On 4WD

Assembling The Air Bags

Assemble the Airbags by bolting on the top and bottom end plates to the alloy rings on the air bags with the 6 threaded bolts and spring washers in the Bottom bracket supplied in the kit.

The 6 Counter sunk screws go in the top brackets. It's important to make sure you leave the 6 bolts in the bottom just loose enough to be able to twist the plate around on the bag to allow for final alignment adjustment during the fitting process. (See the red arrows on the diagram)

Important Note; leave approximately 1 - 2mm gap between the two plates. When bolting the plates to the airbags, tighten the bolts up in a similar way to how you do wheel nuts up on a car. Do the bolts up evenly moving from one side of the plate to the other as shown on the diagram over the page. Make sure the gap is even all the way around. Do not over tighten as this can cause leaks. That's all there is to it!

Strength & Specifications

* Support Wires - 9 High Tensile Central, 4 Each End

* Cured Natural rubber

* Ballistic woven reinforcing

* 6mm Zinc Plated Steel End Caps

* Burst Pressure - Over 600psi

* Independent Test Pressure - 480psi

* Recommended working range - 5psi - 160psi

* Airone air bags have a recommended test pressure of 480psi. That meets the pressure vessel industry guidelines of 3 times the maximum working pressure.

* Airone air bags are undeniably the strongest in the automotive industry and exceed any other airbag brands by nearly double.

* When Airone air bags are utilised in the load assist applications it's virtually impossible to pull the bags apart. Since The air bags started manufacturing ,There never had an airbag fail from bursting.
