Aerpro Dual USB Charge & Sync Harness Suitable for Mitsubishi 19.5mm x 36.5mm

Contents : 1x Aerpro Dual USB Charge & Sync Harness

Suit Vehicle :

Mitsubishi
Mitsubishi Pajero 2000-2006 NM, NP
Mitsubishi Pajero 2006-2014 NS, NT, NW
Mitsubishi Challenger 2009-2013 PB
Mitsubishi Challenger 2013-2015 PC
Mitsubishi Triton 2007-2009 ML [GL, GLX]
Mitsubishi Triton 2007-2009 ML [GLS, GLX-R, VR]
Mitsubishi Triton 2009-2014 MN [GL]
Mitsubishi Triton 2009-2014 MN [GL-R, GLX]
Mitsubishi Triton 2009-2012 MN [GLX-R]
Mitsubishi Triton 2012-2014 MN [GLX-R]
Mitsubishi Triton 2015 MN [GL, GLX, GLX-R]
Mitsubishi ASX 2010-2012 XA
Mitsubishi ASX 2012-2014 XB
Mitsubishi Lancer 2007-2013 CJ
Mitsubishi Outlander 2003-2006 ZE, ZF
Mitsubishi Outlander 2007-2012 ZG, ZH
Mitsubishi Pajero 2012-2019 NW, NX

Description:

Aerpro APUSBMT2 Dual USB Charge & Sync has been designed specifically to suit various Mitsubishi vehicles. It replaces the spare factory switch blanking plates in the vehicle dashboard that measure 19.5mm wide x 36.5mm high (face measurement) / 21mm wide x 38mm high (base measurement), providing seamless USB integration for your vehicle. Featuring two USB ports, one is designed for smartphone and device fast charging at 3A max and the other provides USB pass through sync for Audio, CarPlay & Android Auto when connected to the rear USB input on compatible aftermarket headunits. The USB ports are bidirectional, allowing the cable to be connected either way and the charge port illuminates blue making it easy to find day and night. The clip-in design combined with the simple 3 wire plus USB connection, makes it quick and easy to install, providing a professional and discreet USB upgrade solution for the vehicle.

Important Information:

The AUDIO USB Port is pass through, it will only function when connected to the rear USB input of an aftermarket head unit.

Not recommended for aftermarket head units with a USB lead from rear of unit. Recommended for aftermarket head units with USB port on the rear of unit.

Features

• Suitable for Mitsubishi vehicles with 19.5mm wide x 36.5mm high (face) / 21mm wide x 38mm high (base) switch blanking plates
• Replaces factory switch blanking plates in the dashboard
• Vehicle specific OEM style design for discreet seamless USB integration
• Dual USB ports, one fast charge and one sync pass through
• Charge port supports up to 3 amps max and illuminates blue
• Audio/sync port provides USB pass through for Audio, CarPlay & Android Auto when connected to compatible headunits
• Bidirectional USB ports, allowing the cable to be connected either way
• Ferrite choke on USB cable to reduce signal interference
• Simple clip-in design makes it easy to install with no modifications required
• 3 wire installation; accessory power, illumination, earth/ground, plus USB connection

Specifications

• VEHICLE APPLICATION: VARIOUS MITSUBISHI VEHICLES
• PANEL DIMENSIONS:
• BODY: 21MM (W) X 38MM (H)
• FACE: 19.5MM (W) X 36.4MM (H)
• CONNECTION TYPE: DUAL USB
• USB 1: FAST CHARGE 3.0A MAX
• USB 2: PASS THROUGH (AUDIO AND SYNC)
• MOUNTING TYPE: CLIP-IN
• WIRING INSTALLATION:
• 12V+ ACCESSORY POWER: RED
• EARTH: BLACK
• ILLUMINATION: BLUE
• USB CONNECTION: USB-A
• NOTES:
• The AUDIO USB Port is pass through, it will only function when connected to the rear USB input of an aftermarket head unit.
• Not recommended for aftermarket head units with a USB lead from rear of unit. Recommended for aftermarket head units with USB port on the rear of unit.
