Aerpro 10" Multimedia Receiver - with Rear USB Input & Built-in Bluetooth

Contents : 1x Aerpro 10" Multimedia Receiver

Description:

The Aerpro AM10X Multimedia Receiver with Wireless Apple CarPlay and Android Auto features a large 10" capacitive touch screen display. The built-in Bluetooth enables hands-free phone calls and wireless audio streaming and the included external microphone provides crystal clear communications. It has a rear USB input which works with Apple CarPlay and Android Auto, as well as a built in AM/FM tuner with RDS and presets. Sound quality is superb with a built in 40W x 4 amplifier, 8 band graphic EQ and time alignment capabilities for precise sound adjustment. If more sound is desired, an amplifier can be added to the system via the 4V/5CH RCA preouts (front + rear + subwoofer). The unit is OEM steering wheel remote ready and has a reverse camera input (720P AHD compatible).This head unit is not sold separately, it is sold as part of a complete vehicle specific installation kit.

This head unit is a short chassis double din unit with fixed face design. It is compatible for use with Aerpro 10" Facia Kits only. It is not designed to fit into a standard double din facia kit.

Features

• Large 10" capacitive touchscreen LCD (1024 x 600)
• Works with Apple CarPlay (wireless or wired)
• Supports Android Auto (wireless or wired)
• Built-in Bluetooth (A2DP, AVRCP, HFP, PBAP)
• Hema Maps Ready, experience seamless on-road and off-road navigation through the head unit display (optional AMHXD3 required, sold separately)
• AM / FM Tuner with RDS & presets (18FM/12AM)
• Reverse camera input (AHD 720P compatible)
• Rear A/V input
• 4V / 5CH RCA Preout
• MP3 / AAC / FLAC / MPEG 1,2,4 Media formats
• Rear USB input (1.5A max charging)
• 8 Band graphic EQ
• 8 EQ Presets
• Time alignment capabilities
• Subwoofer level control
• 40W x 4 Max built-in amplifier
• Shallow 2-DIN chassis mounting design
• Steering wheel control ready
• External microphone included

Specifications

• LCD Display:
• Size: 10"
• Resolution: 1024x600
• Touch Screen: Capacitive (G+G)
• System Specifications:
• OS System / CPU: Linux 3.4.5 / SPHE8368U
• RAM / Flash Memory: 128MB / 256MB
• DIN Size: 2 DIN Short Body
• Power Output
• Rated Power (4 Ohm @ 14.4 V, 1 kHz, THD 10 %): 4CH x 25W
• MAX Power (4 Ohm): 4CH x 40W
• Media Playback: MP3 / AAC / FLAC / Xvid / MPEG 1, 2, 4
• Device Ports
• USB (Rear) Playback Formats: CPAA & Media
• USB (Rear) Power - Voltage/Amps: 5V/1.5A
• USB MAX Capability: FAT32_32GB
• Aux Inputs / Outputs:
• Rear A/V Input (RCA Type - 3pcs): Yes
• Composite Video Outputs: Yes
• Reverse Camera Input: Yes (720P AHD Compatible)
• Smartphone Connectivity: CarPlay & Android Auto (Wireless and Wired)
• Bluetooth:
• Bluetooth Built-In: Yes (A2DP, AVRCP, HFP, PBAP)
• Bluetooth Version: V4.2+EDR
• Microphone: Built-in & External Microphone
• ID3 Tag/Information (Artist, Album, Song): Yes
• HFP Profile (1.2, 1.4 or HD Voice 1.6): HFP 1.6
• Tuner:
• AM/FM (# of Presets): AM 12 (6X2) / FM 18 (6X3)
• FM Frequency Span (MHz): 87.5-108.0MHz (0.05MHz Step)
• AM Frequency Span (KHz): 529-1629KHz (9KHz Step)
• RDS: Yes
• FM Antenna Connector Impedance: 50 Ohm
• FM Tuner Connector: Motorola
• RCA Preamp Outputs:
• RCA Preamp Output: 2-Pair (Front / Rear)
• Subwoofer RCA Output: Yes
• Subwoofer Level Control: Yes
• Preamp Voltage (1.2,2,4,5,6): 4V p-p
• Tone Control:
• 8 Band: 8 Band (50/200/400/800/1K/3K/7K/15K)
• Loudness: Yes
• LPF - Frequencies (Sub): Yes
• 8 Preset EQs: Default, Custom, Classic, Rock, Jazz, Electric, Pop, Soft
• Other Features:
• Steering Wheel Control: Yes, with Aerpro SWC Adaptor
• OSD Language: English
• LED Colour (Buttons / Keys): White
• Accessories:
• Power Harness: Yes with ISO/3.5mm jack
• AV-In Cable (RCA with Audio L/R, Video In): Yes
• Reverse Camera Input (with 12V power supply to the camera): Yes
• 4.1CH Audio Out Cable: Yes
• External Microphone: Included
• Important Information:
• This head unit is not sold separately, it is sold as part of a complete vehicle specific installation kit.
• This head unit is a short chassis double din unit with fixed face design. It is compatible for use with Aerpro 10" Facia Kits only. It is not designed to fit into a standard double din facia kit.
