Aerpro 10" Multimedia Receiver with Black Facia for Volkswagen Various Models

Contents : 1x Aerpro 10" Multimedia Receiver

Suit Vehicle :

Volkswagen Amarok 2011-2016
Volkswagen Beetle 2012-On
Volkswagen Caddy 2005-2015
Volkswagen EOS 2007-2014
Volkswagen Golf 2004-2009 MK5
Volkswagen Golf 2009-2013 MK6
Volkswagen Jetta 2006-2015
Volkswagen Passat 2006-2015
Volkswagen Polo 2010-2014
Volkswagen Scirocco 2009-2014
Volkswagen Tiguan 2008-2014
Volkswagen Transporter T5 2010-2015

Description:

The Aerpro AMVW2 10" Multimedia Receiver with Wireless Apple CarPlay and Android Auto suits Volkswagen Amarok (2011-2016)*, Beetle (2012- 2014), Caddy (2005-2015), Eos (2007-2014), Golf (2004-2013)*, Jetta (2006-2015)*, Passat (2006-2015)*, Polo (2010-2015)*, Scirocco (2009-2014)*, Tiguan (2008-2014)* and Transporter (2010-2015) vehicles. Featuring a large 10" capacitive touchscreen display, this Multimedia Receiver has Apple CarPlay and Android Auto which can be used wireless or wired, built-in Bluetooth for hands-free phone calls & wireless audio streaming, rear USB input as well as an AM/FM radio tuner. Sound quality is superb with 40Wx4 max output, 8 band graphic EQ and time alignment capabilities, amplifiers can be added to the system via the 4V/5CH RCA preouts. Supplied as a complete Head Unit Upgrade Kit, the Aerpro AMVW2 includes all the parts required to complete the installation and retains important vehicle features including steering wheel controls and the factory amplified system (model dependant**).Head Unit Upgrade Kits can vary between vehicle models, please use the Aerpro What Fits Your Car Guide to find the correct parts.

(*) Due to the size of the head unit, please be aware of the following:

Amarok (2011-2016): Kit may partially cover top buttons.

Golf (2004-2009): Kit covers vent dial, may still be accessible but not tested.

Jetta (2006-2011): Kit covers vent dial, may still be accessible but not tested.

Passat (2006-2015): Kit covers part of hazard or clock on some models.

Polo (2010-2015): Kit covers part of buttons.

Scirocco (2009-2014): Kit covers vent adjusters.

Tiguan (2008-2014): Kit partially covers hazard button.

(**) Factory amplifier retention:

Compatible with factory Panasonic amplified systems.

Not compatible with factory Blaupunkt amplified systems, for these vehicles please use the Aerpro AMVW3 Head Unit Upgrade Kit.

May need a trigger wired in for the amplifier.

This head unit is sold as a kit which includes:

AM10X Multimedia Receiver

Matte Black Facia Kit

Steering Wheel Control Interface Harness

SWC Patch Lead

Amplifier Retention Harness

Antenna Adaptor

Features

• To suit Volkswagen Amarok (2011-2016)*, Beetle (2012- 2014), Caddy (2005-2015), Eos (2007-2014), Golf (2004-2013)*, Jetta (2006-2015)*, Passat (2006-2015)*, Polo (2010-2015)*, Scirocco (2009-2014)*, Tiguan (2008-2014)* and Transporter (2010-2015) vehicles
• Includes all the parts required to complete the installation
• Apple CarPlay & Android Auto (wireless / wired)
• Hema Maps Ready, experience seamless on-road and off-road navigation through the head unit display (optional AMHXD3 required, sold separately)
• Large 10" capacitive touchscreen display
• Steering wheel control and factory amplified system (model dependant**) retention
• Bluetooth with external microphone included (A2DP, AVRCP, HFP, PBAP)
• AM / FM Tuner with RDS & presets (18FM/12AM)
• Rear USB input (1.5A max charging)
• Reverse camera input (AHD 720P compatible) & rear A/V input
• 40Wx4 Max with 8 band graphic EQ and time alignment capabilities
• 4V/5CH RCA Preout and subwoofer level control

Specifications

AMVW2 HEAD UNIT UPGRADE KIT SPECIFICATIONS:

Kit Inclusions:

AM10X Multimedia Receiver
Matte Black Facia Kit
Steering Wheel Control Interface Harness
SWC Patch Lead
Amplifier Retention Harness
Antenna Adaptor

Vehicle Feature Retention:

Steering Wheel Controls: Yes (including phone button)
Factory Reverse Camera: No
AUX Input: N/A
USB Input: N/A
Parking Tones: No
Factory Amplifier: Yes (model dependant**)
Vehicle Menu: N/A
Other: N/A

AM10X MULTIMEDIA RECEIVER SPECIFICATIONS:

LCD Display:

Size: 10"
Resolution: 1024x600
Touch Screen: Capacitive (G+G)

System Specifications:

OS System / CPU: Linux 3.4.5 / SPHE8368U
RAM / Flash Memory: 128MB / 256MB

DIN Size:2 DIN Short Body

Power Output

Rated Power (4 Ohm @ 14.4 V, 1 kHz, THD 10 %): 4CH x 25W
MAX Power (4 Ohm): 4CH x 40W

Media Playback:MP3 / AAC / FLAC / Xvid / MPEG 1, 2, 4

Device Ports

USB (Rear) Playback Formats: CPAA & Media
USB (Rear) Power - Voltage/Amps: 5V/1.5A
USB MAX Capability: FAT32_32GB

Aux Inputs / Outputs:

Rear A/V Input (RCA Type - 3pcs): Yes
Composite Video Outputs: Yes
Reverse Camera Input: Yes (720P AHD Compatible)

Smartphone Connectivity: CarPlay & Android Auto (Wireless and Wired)

Bluetooth

Bluetooth Built-In: Yes (A2DP, AVRCP, HFP, PBAP)
Bluetooth Version: V4.2+EDR
Microphone: Built-in & External Microphone
ID3 Tag/Information (Artist, Album, Song): Yes
HFP Profile (1.2, 1.4 or HD Voice 1.6): HFP 1.6

Tuner

AM/FM (# of Presets): AM 12 (6X2) / FM 18 (6X3)
FM Frequency Span (MHz): 87.5-108.0MHz (0.05MHz Step)
AM Frequency Span (KHz): 529-1629KHz (9KHz Step)
RDS: Yes
FM Antenna Connector Impedance: 50 Ohm
FM Tuner Connector: Motorola

RCA Preamp Outputs:

RCA Preamp Output: 2-Pair (Front / Rear)
Subwoofer RCA Output: Yes
Subwoofer Level Control: Yes
Preamp Voltage (1.2,2,4,5,6): 4V p-p

Tone Control:

8 Band: 8 Band (50/200/400/800/1K/3K/7K/15K)
Loudness: Yes
LPF - Frequencies (Sub): Yes
8 Preset EQs: Default, Custom, Classic, Rock, Jazz, Electric, Pop, Soft

Other Features:

Steering Wheel Control: Yes, with Aerpro SWC Adaptor
OSD Language: English
LED Colour (Buttons / Keys): White

Accessories:

Power Harness: Yes with ISO/3.5mm jack
AV-In Cable (RCA with Audio L/R, Video In): Yes
Reverse Camera Input (with 12V power supply to the camera): Yes
4.1CH Audio Out Cable: Yes
External Microphone: Included

IMPORTANT INFORMATION

Head Unit Upgrade Kits can vary between vehicle models, please use the Aerpro What Fits Your Car Guide to find the correct parts.
(*) Due to the size of the head unit, please be aware of the following:
Amarok (2011-2016): Kit may partially cover top buttons.
Golf (2004-2009): Kit covers vent dial, may still be accessible but not tested.
Jetta (2006-2011): Kit covers vent dial, may still be accessible but not tested.
Passat (2006-2015): Kit covers part of hazard or clock on some models.
Polo (2010-2015): Kit covers part of buttons.
Scirocco (2009-2014): Kit covers vent adjusters.
Tiguan (2008-2014): Kit partially covers hazard button.
(**) Factory amplifier retention:
Compatible with factory Panasonic amplified systems.
Not compatible with factory Blaupunkt amplified systems, for these vehicles please use the Aerpro AMVW3 Head Unit Upgrade Kit.
May need a trigger wired in for the amplifier.
