1 x Brand New Airone Suspension Load Assist Single Air Bag 2401 Bare

Content : 1 x Single Air Bag 2401 Bare

specifics :

Fully Compressed :55mm with 6mm ends fitted

Max Diameter: 135mm (widest when fully compressed)

Max Height :110mm

Max Working Pressure :0~160psi

Test Pressure :480psi

Burst Pressure :750psi

Strength & Specifications

* Support Wires - 9 High Tensile Central, 4 Each End

* Cured Natural rubber

* Ballistic woven reinforcing

* 6mm Zinc Plated Steel End Caps

* Burst Pressure - Over 600psi

* Independent Test Pressure - 480psi

* Recommended working range - 5psi - 160psi

* Airone air bags have a recommended test pressure of 480psi. That meets the pressure vessel industry guidelines of 3 times the maximum working pressure.

* Airone air bags are undeniably the strongest in the automotive industry and exceed any other airbag brands by nearly double.

* When Airone air bags are utilised in the load assist applications it's virtually impossible to pull the bags apart. Since The Airone air bags started manufacturing ,There never had an airbag fail from bursting.

The Airone Extreme series airbags are rated at 2500lb or 1136kg per side and have been government approved tested to over 750psi.

Average dual cab ute will run around 15-45psi depending on load.

The proprietary ballistic material used for the woven reinforcing on the airbag wall, along with the specific spacing and angle of the weave, is what gives our air bag its' unique strength.
